SRNE HESP Series (8kW–12kW)

Single-Phase Hybrid Solar Storage Inverters

The SRNE HESP Series 8kW–12kW is designed for high-performance hybrid and off-grid solar applications, delivering powerful energy conversion, advanced protection layers, and next-generation MPPT technology. With a robust IP65-rated enclosure, the HESP series is engineered for both residential and commercial environments that demand durability, reliability, and seamless solar-battery-grid interaction.

Developed using SRNE’s 15+ years of R&D leadership and backed by over 200 global patents, the HESP lineup stands as one of the most sophisticated and efficient hybrid inverter solutions in the market today.

⭐ Key Features of the SRNE HESP Series

1. High MPPT Efficiency Up to 99.9%

Equipped with two independent MPPT trackers delivering extremely fast and accurate solar tracking for maximum PV harvesting in all conditions.
(From datasheet: “MPPT Tracking Efficiency 99.9%”)

SRNE_HESP series_EU_48V_8~12kW_…

2. Wide Battery Compatibility (48V Lithium & Lead-Acid)

Supports multiple battery options including Li-ion, lead-acid, and user-defined configurations, offering full flexibility for villas, homes, shops, and industrial systems.
(Battery compatibility listed on page 2.)

SRNE_HESP series_EU_48V_8~12kW_…

3. Powerful Solar Input With Wide MPPT Range

The HESP Series supports 5.5kW+5.5kW or 6.6kW+6.6kW PV input depending on model, with a 120–450V MPPT voltage range for better string design and superior energy generation.
(PV input values from datasheet.)

SRNE_HESP series_EU_48V_8~12kW_…

4. Hybrid Charging Modes for Maximum Efficiency

Smart charging management across solar, generator, and grid sources optimizes energy flow while extending battery life.
(Supports solar/grid/generator hybrid charging.)

SRNE_HESP series_EU_48V_8~12kW_…

5. Advanced Multi-Layer Protection System

Full protection suite including:

• PV reverse protection

• Anti-islanding protection

• Output short-circuit

• Over-voltage & under-voltage

• AC/DC surge protection

• Over-current & overload protection

• Temperature protection
  (All protection features documented in datasheet.)

  SRNE_HESP series_EU_48V_8~12kW_…

6. IP65 Waterproof Enclosure

The HESP series is built with an IP65 outdoor-rated design, delivering superior durability in harsh environmental conditions such as dust, heat, and humidity.
(Listed on page 1.)

SRNE_HESP series_EU_48V_8~12kW_…

7. Smart Communication & Monitoring

Equipped with RS485, CAN, USB, Dry Contact, and optional Wi-Fi/GPRS, enabling real-time data access, remote monitoring, and seamless integration with energy management systems.
(Communication standards listed on page 2.)

SRNE_HESP series_EU_48V_8~12kW_…

8. Efficient Thermal Management

Advanced internal fan cooling ensures long-term stability and optimal system performance even under high load and high-temperature conditions.

⚡ Technical Highlights

• Rated Power: 8.8kW / 10kW / 12kW (model-dependent)

• Pure sine wave output

• Ultra-fast switching time: ~10ms

• Wide PV voltage range: 120–450V

• Parallel support: up to 6 units, with the ability to form a 3-phase system

• High efficiency: 97–97.5% max

• Storage battery voltage: 48V
  (All values referenced from the datasheet.)

  SRNE_HESP series_EU_48V_8~12kW_…
